09 January 2014

Railbus Launching

An old railbus advertisement scanned from the New Straits Times.


Picture credits: New Straits Times
Scanned by: zacky

Copy from : http://www.facebook.com/ktmrfc

09 December 2013

ELECTRIFIED DOUBLE TRACKING PROJECT BETWEEN SUBANG JAYA AND TERMINAL SKYPARK



OBJECTIVE

To provide brief description regarding the implementation of Electrified Double Tracking Project in between Subang Jaya and Terminal Skypark and to gather feedback from the public regarding the Project.

LOCATION
  1. Majlis Bandaraya Shah Alam
  2. Majlis Bandaraya Petaling Jaya
  3. Pejabat Setiausaha Kerajaan Negeri Selangor
  4. Suruhanjaya Pengangkutan Awam Darat
  5. KL Sentral

Proposed Public Display Date : 2 December 2013 until 28 February 2014.

PROJECT BERIEF

Electrified Double Tracking Project Between Subang Jaya and Terminal Skypark was funded by the Government through Ministry of Transport to provide rail based public transport especially to connect the Sultan Abdul Aziz Shah (SAAS) Airport Terminal and the vicinity area with the existing railway network.

The proposed project will be mainly based on the current Klang Valley electrified double tracking system which provides the existing commuter services.

The proposed Sri Subang branch line commence from Batu Caves – Pelabuhan Klang Main Line take off point at Km 17.37 of Subang Jaya – Batu Tiga section with a total route length of 8.157km and terminated at Terminal Skypark Station which is located in front of existing Terminal 3, SAAS Airport.

The above project involves 25kV Overhead Catenary System, Modern Signalling and Communication System and also integration with the existing Centralised Train Control (CTC) at KL Sentral. It was envisaged that the shuttle service for commuter will run between Terminal Skypark and KL Sentral once the project completed.

The services could be integrated with the future LRT Extension Project at Subang Jaya Station once both the project completed.

Generally, the above project consists of two main section ie. at grade section in between Subang Jaya and Sri Subang for the length of 4.09km using the existing railway reserve and also the elevated section in between Sri Subang and Terminal Skypark for the total length of 4.067km which is along the existing Sungai Damansara river reserve.

It will involves the construction of one terminal station ie. Terminal Skypark Station at Ch 8000 with the provision of side platform at 150 m length.

Future halt development was also identified at Glenmarie Halt (Ch1975) and Sri Subang Halt (Ch4625) but the implementation of the halt is subject to the demand from the public once the project completed. The proposed alignment is shown as part of the display

COMMENCEMENT : 21 FEBRUARY 2013
COMPLETION : 20 FEBRUARY 2016

PROJECT BENIFITS

To provide the rail based public transport to the public especially to the passenger of Sultan Abdul Aziz Shah Airport and the vicinity areas and connect with the existing Klang Valley rail network. As such, the passenger can be connected to Kuala Lumpur International Airport Sepang via rail through interchange point at KL Sentral. It will provide environmental friendly based services which indirectly reduce the existing road congestion and also increasing the usage of public transport from the public with the better and more comprehensive railway network mainly KTMB, LRT and MRT.

PROPOSED SYSTEM COMPONENT

Communication and Signalling System for Subang Jaya and Terminal Skypark can be control directly from Centralised Train Control Centre at KL Sentral.

Bi-directional movement signalling system which is control automatically through the movement of train with three aspects signalling system. Block signalling system can be control through the axle counter and track circuit within station area.

Communication system with digital transmission system SDH STM-4 for all communication medium at the station and integration to CTC KL Sentral. The communication system also included Fiberail and TM Fiber network.

25kV AC 50Hz Single Phase Overhead line electrification system for the existing Klang Valley electrification system will be extended for the above project. The proposed electrification system for Subang Jaya – Terminal Skypark section will be integrated to the Electrical Control Room (ECR) at CTC KL Sentral.

ROLLING STOCK

It was envisaged that KTMB will be utilizing the existing Class 81 / 82 / 83 EMU Set

CAPACITY

400 / 200 seated

PROPOSED INTERVAL

15 / 30 minutes (peak / non-peak period)

STATION CLASIFICATION

Major Station / Terminal Station

TYPE OF PLATFORM

Side Platform

STATION FACILITIES

Carpark and motorcycle parking area, disable toilet, Male/Female toilet, ramp with railing, Lift, Escalator, CCTV, Passenger information System and Public Address, Kiosk, Male/Female Surau, Auxiliary police booth, Ticket Counter and Ticket Vending Machine.

FIRE FIGHTING SYSTEM AND SAFETY

Proposed Fire Rated Door, Automatic Alarm System Detector, Fire Fighting System and Fire Hydrant.

PROPOSED FARE STRUCTURE

JIt is envisaged that the fare between Terminal Skypark to KL Sentral for commuter services is in between RM 1.20 to RM 1.50.

TECHNICAL FEATURES
  • Fully automatic signalling with Automatic Train Protection (ATP)
  • Disabled Facilities
  • Service Interval : 15 minutes / 30 minutes for peak and non-peak period
  • Average Speed : 60km/h
  • Average Idle Time : 1 minutes
  • Numbers of Station : 1 number at Skypark Terminal Station
  • Length of Route : 8.157 km
  • Operation Hours : 0600 –  2400 hour
  • Type of Platform : Side Platform

Communication
  • Fully integrated with the existing system
  • Fully communication system coverage
  • Public Information Display
  • Closed Circuit Television at station area and platform
  • Public address system
  • Fully centralised control from CTC KL Sentral
  • Fibre optic infrastructure

Tracks
  • Upgraded track component
  • Low vibration and noise
  • In line with the current electrified double tracking system
  • Comfortable ride
  • Metre gauge track with 54E1 rail and concrete sleeper

Signalling
  • Monitor operation speed for safer journey
  • Monitor movement of train based on the timetable
  • Integrated with the Klang Valley existing system
  • Bidirectional movement on both tracks
  • Maximum speed of 110 km/h
  • Train detection system
  • Fully interlocking system to avoid collision
  • Automatic route indicator

Power supply
  • Power supply from the existing Subang Jaya Feeder Station
  • Monitor power supply from Electrical Control Room at CTC KL Sentral
  • Utilizing the overhead catenary system of 25kV AC 50Hz single phase

Automatic Fare Collection (AFC) System
  • Ticket vending machine and ticket counter
  • Integration with other modes of transport
  • The existing AFC can be upgraded in line with the demand

Operations and maintenance
  • Safety Plan for passenger and staff
  • Maintenance depot for rolling stock

SAFETY FEATURES

Compliance with the existing safety manual practice in Malaysia

Station
  • Lighting system
  • CCTV at suitable location for monitoring purposes
  • Station master and auxiliary police
  • Smoke / fire detection system

Rolling stock
  • Automatic Train Protection system
  • Man operated train

Tracks
  • Safe for operations with regular maintenance
  • Boundary fence along the alignment to deter encroachment
  • Dedicated walkway route along the track

Operations
  • Fully signalling system
  • Full operation control from CTC KL Sentral

FOR MORE INFORMATION
Please contact


KERETAPI TANAH MELAYU BERHAD
En. Ismail Said
Tel. No. : 03-2263 1270
Email: ismailsa@ktmb.com.my

KONSORTIUM SKYPARK LINK – LION PACIFIC
Puan Syarwani Bt. Abd Kadir @ Jaafar
Tel. No. : 03-7832 6635
Email: syarwani@skyparklink.com

KL CONSULT ASSOCIATES SDN. BHD.
En. Arshad B. Puasa
Tel. No. : 03-7832 6635
Email: skyparkrail@klconsult.com

11 October 2013

Tren elektrik KL-Kuala Kangsar-KL beroperasi tahun depan



LENGGONG 9 Okt. - Perkhidmatan tren elektrik (ETS) Keretapi Tanah Melayu Berhad (KTMB) bagi laluan Kuala Lumpur-Kuala Kangsar-Kuala Lumpur dijangka beroperasi mulai awal tahun depan.

Pengurus Kanan Pemasaran, KTMB Antarabandar, Mohd. Noordin Kimi berkata, pembukaan stesen terbaharu ETS itu diyakini dapat meningkatkan lagi jumlah penumpang antara lima hingga 10 peratus daripada lebih 3.3 juta pengguna sedia ada.

"Pertambahan laluan ini diharap akan membantu memperkasakan lagi sektor pelancongan di daerah Kuala Kangsar yang mempunyai pelbagai keunikan dan sejarah tersendiri.

"Selain untuk menarik pelancong, perkhidmatan ETS juga dijangka mampu menjadi mod pengangkutan utama buat penduduk tempatan yang bekerja di ibu kota, sekali gus memberi alternatif kepada mereka untuk berulang-alik ke Kuala Kangsar-Kuala Lumpur dalam tempoh kurang daripada tiga jam," katanya.

Beliau berkata demikian dalam siri lawatan KTMB bersama media di Homestay Kampung Beng, Lenggong, di sini hari ini.

Lawatan selama tiga hari bermula Isnin lalu itu bertujuan mendedahkan wakil pelbagai media dengan pelancongan menggunakan kereta api di satu-satunya inap desa yang terdapat di Parlimen Lenggong, sekali gus mempromosikan perkhidmatan ETS bagi laluan Kuala Kangsar.

Dalam perkembangan sama, Noordin memberitahu, penjadualan semula perkhidmatan ETS sejak 1 Oktober lalu pada waktu puncak di sebelah petang diharap dapat membantu mempercepatkan perjalanan penumpang ke destinasi masing-masing.

Jelasnya, bermula dari pukul 4 petang hingga 9 malam, orang ramai berpeluang menikmati kemudahan ETS dalam tempoh setiap satu jam berbanding operasi normal iaitu dua jam sekali.

"KTMB sentiasa berusaha menambah baik perkhidmatannya terutama ETS yang semakin mendapat tempat dalam kalangan pengguna apabila secara purata didapati dinaiki kira-kira 6,000 penumpang dalam sehari," ujarnya.

Artikel Penuh: http://www.utusan.com.my/utusan/Dalam_Negeri/20131010/dn_15/Tren-elektrik-KL-Kuala-Kangsar-KL-beroperasi--tahun-depan#ixzz2hH9pAct2
© Utusan Melayu (M) Bhd
