19 July 2009

FMSR Class I

The FMSR Class I was built for the FMSR by three locomotive companies between 1907 and 1916 and delivered in five batches between 1908 and 1916.

Upon the delivery of the last batch, the Class I included a total of 31 locomotives. The Class I was a 0-6-4T tank locomotives with tanks of varying sizes: The first batch featured 800 gallon tanks, while the third batch featured 1200 gallon tanks.

The first batch, delivered 1908, encompassed five locomotives from Kitson (works numbers 4527 to 4531) built between December 1907 and January 1908, followed by an additional three from North British in 1912 (works numbers 19909 to 19911), eight and ten from Kitson in 1913 (works numbers 4946 to 4953) and 1914 (works numbers 5021 to 5030), and five from Hawthorn Leslie in 1916 (works numbers 3146 to 3150).

Between 1927 and 1945, 13 Class I were decommissioned.While 18 Class Is remained in service in 1946 to receive a new locomotive number, virtually all of the class were withdrawn from the FMSR's and MR's rolling stocks by 1953. Two Class Is were sold to the Malayan Collieries in 1951 and 1953.
